# New DJI Avinox M2 and M2S Motors: Specs and Comparison for eMTB
DJI Avinox has released the M2 and M2S motor series for electric bikes. These motors combine peak power up to 1500 W, high torque, and minimal weight. They integrate with high-density batteries and software for precise control. The first bike based on the M2 is the Amflow from DJI.
The flagship M2S version delivers 1500 W and 150 Nm at a weight of 2.59 kg. The standard M2 provides 1100 W and 125 Nm at 2.65 kg. Both motors retain the compact dimensions of the predecessor M1 but surpass it in specific performance metrics.
Technical Specifications and Advantages
The M2S boosts specific power by 45% and specific torque by 21.6% compared to the M1. Key improvements:
- Dual gear meshing in the M2S eliminates play and clicks when stopping pedaling.
- Helical gears in the M2 achieve a similar effect.
- Noise level does not exceed 45 dB(A) at maximum power.
Heat dissipation is achieved through flat windings and cooling fins. This minimizes energy losses, allowing the motor to sustain peak performance longer during climbs without throttling due to overheating.
Comparison with Competitors:
| Model | Peak Power, W | Torque, Nm | Weight, kg |
|--------|----------------------|----------------------|---------|
| DJI Avinox M2S | 1500 | 150 | 2.59 |
| DJI Avinox M2 | 1100 | 125 | 2.65 |
| Bosch CX Gen 5 | 600 | 85 | 2.8 |
| Specialized Levo R | 850 | 111 | - |
| MAHLE M40 | 1200 | 120 | - |
The data shows Avinox's superiority in power and torque at comparable or lower weight.
Batteries and Charging
Full 1500 W power is available with the integrated FP700 battery (700 Wh). Charging from 0 to 80% takes 76 minutes thanks to GaN technology. Additionally:
- Removable RS800 and RS600 charge separately.
- RS600 mounts to the frame as a range extender.
- Compatibility with M1 batteries.
Displays and Controls
2-inch OLED screen with touch interface operates standalone. Import GPX, FIT, TCX routes from Komoot without a smartphone. Versions:
- DP100-F: base.
- DPC100: with Apple Find My for tracking.
The Avinox Ride app lets you set a target heart rate zone. The motor adapts power: reduces it when comfortable, increases it under load. M1 motors, batteries, and displays are compatible with M2.
Key Points
- M2S: 1500 W, 150 Nm, 2.59 kg — leader in specific performance.
- Noise ≤45 dB(A), improved heat dissipation for long climbs.
- GaN charging for FP700: 80% in 76 min, removable options.
- Standalone OLED display with navigation and Find My.
- Adaptive control based on HR in the app.
— Editorial Team
