Docker on VPS: 24 containers in production

24 Containers on a Single VPS: High-Density Technical Architecture for Middle/Senior DevOps

One server, 6 GB RAM, 24 containers — and everything runs stably for over a year. This is not an experiment, but production infrastructure supporting seven active projects: an EdTech bot, an anti-spam service, an AI backend, a meta-search engine, local LLM inference, and two utility services. None of them generate revenue, yet all are critical to operational activities. The goal was not cost-cutting for its own sake, but a conscious trade-off: manual management instead of managed services, predictable load instead of cloud elasticity, and deep integration instead of abstraction.

Architectural Principles: Isolation, Observability, Resilience

The core approach relies on strict network isolation. Each project resides in its own Docker network (bridge), eliminating cross-dependencies and minimizing the attack surface. A shared shared network is used only for system services (e.g., monitoring or common Redis). Internal ports (9200, 8088, 9222) are accessible exclusively via 127.0.0.1; external access is blocked at the iptables and nginx configuration levels.

Resilience is ensured through healthcheck dependencies in docker-compose.yml. For example, PHP services in the EdTech project do not start until an SSH tunnel to the remote database passes an nc -z 127.0.0.1 3306 check. This guarantees the application won't attempt to connect to an unavailable database and crash the queue with errors.

Observability is built without Prometheus/Grafana due to RAM constraints. Instead, a bash script runs every 15 minutes:

• Checks HTTP status codes of public endpoints (/health, /webhook/advert)
• Identifies unhealthy containers via docker ps --filter "health=unhealthy"
• Monitors disk space and swap usage
• Sends alerts to a Telegram chat via curl to the Bot API

This provides minimal but sufficient visibility for a single administrator.

Critical Components: Elasticsearch, Chrome Headless, and SSH Tunnels

Three components define the performance boundaries of the VPS:

• Elasticsearch 8.12.2 consumes 1.47 GB RAM. Without an explicit memory: 2g limit in deploy.resources.limits, the JVM begins swapping out neighboring processes, causing instability. For an index of ~50K documents and logging, this offers the optimal balance between functionality and load. An alternative like Meilisearch would require migrating existing indexes and modifying client code, rated as a high-effort, low-ROI task at this stage.

• Chrome Headless (zenika/alpine-chrome) occupies 636 MB RAM, though it is used only once an hour for JS rendering scraping. Running on-demand via docker run --rm would save memory but add a 5–10 second delay per call. For services with strict SLAs, this is unacceptable; here, it is an acceptable compromise.

• SSH Tunnels are implemented in separate alpine containers with autossh. They provide secure access to MySQL on a shared host without opening ports externally. Configuration includes ServerAliveInterval=30, AUTOSSH_GATETIME=0, and a healthcheck via nc. This solution works with all hosts supporting SSH and fully replaces paid managed databases.

Nginx and PHP Optimization: Reducing Latency by Milliseconds

Nginx is configured exclusively for webhooks and APIs — no static files except /health. The key optimization is offloading Telegram webhook processing to a separate PHP file (webhook-advert.php) that bypasses the Laravel bootstrap. This reduces response time from 80–120 ms to 15–25 ms, which is critical during mass webhook calls from the Telegram API (max timeout — 60 seconds).

Configuration also includes:

• Forced HTTP → HTTPS redirect
• Refusal to process any paths other than /health, /webhook/, and /api/telegram/
• Increased fastcgi_read_timeout to 120 seconds for long-running tasks
• Use of realpath_root for correct index.php handling

SSL and Security: Three Strategies on One Host

SSL termination is organized hybridly:

• getssl + Let's Encrypt — for domains requiring end-to-end encryption without Cloudflare
• Cloudflare Proxy — for most domains: SSL terminates at the edge, traffic to VPS goes over HTTP, but protected by IP filtering (only Cloudflare ASN)
• Manual Update — a temporary measure for the AI backend, currently undergoing automation via Caddy

Cloudflare setup includes mandatory Always Use HTTPS, WAF, and Rate Limiting (100 requests/min per IP), compensating for the lack of WAF on the VPS side.

Key Takeaways

• Strict network isolation via separate Docker networks prevents cascading failures and simplifies security audits.
• Healthcheck dependencies in docker-compose ensure services start only after their dependencies are ready (e.g., SSH tunnel to DB).
• Elasticsearch requires a hard memory limit (2 GB); otherwise, the JVM swaps out neighboring containers, triggering the OOM killer.
• Keeping Chrome Headless in always-on mode is justified at low usage frequency if startup latency is critical for business logic.
• Bash monitoring with Telegram alerts is a working replacement for Prometheus/Grafana under RAM constraints, provided SLOs are clearly defined.
