MTProto proxy: personal secrets and policies

Personal MTProto Proxies on Erlang: Policy System and Unique Secrets

MTProto proxies provide access to Telegram under censorship. The traditional model uses a single secret key for all users, leading to issues: lack of access control, inability to analyze user activity, and limited monetization. The solution is personal secrets with a unique SNI domain for each client, implemented in Erlang mtproto_proxy via a policy system.

This implementation scales through O(1) connection validation and runtime-configurable rules. It supports connection limits, access revocation, and activity tracking without server restart.

Advantages of Erlang for High-Load Proxies

Erlang/OTP is ideal for MTProto proxies due to its architecture designed for millions of long-lived connections:

• Process isolation: Each connection is a separate lightweight process (~2 KB). A crash in one does not affect others.
• Auto-scaling: BEAM distributes processes across all CPU cores without manual management.
• Preemptive multitasking: No single client can monopolize a core.
• Bit syntax for parsing: Safe parsing of TLS ClientHello in one line:

parse_client_hello(
  <<?TLS_REC_HANDSHAKE, ?TLS_10_VERSION, TlsFrameLen:16,
    ?TLS_TAG_CLIENT_HELLO, HelloLen:24, ?TLS_12_VERSION,
    Random:32/binary,
    SessIdLen, SessId:SessIdLen/binary,
    CipherSuitesLen:16, CipherSuites:CipherSuitesLen/binary,
    CompMethodsLen, CompMethods:CompMethodsLen/binary,
    ExtensionsLen:16, Extensions:ExtensionsLen/binary>>
) when TlsFrameLen >= 512, HelloLen >= 508 -> ...

• Live monitoring: Remote console for inspecting tables and states.
• Hot updates: Changing code and configuration without breaking connections.

Total code volume is 3500 lines, less than most alternatives.

SNI and Fake-TLS Secret Format

Server Name Indication (SNI) allows a client to specify a domain in ClientHello before completing the TLS handshake. Fake-TLS mimics TLS 1.3 ClientHello with a legitimate SNI, hiding MTProto inside encrypted fields.

Personal secret format:

0xEE | <16 random bytes> | <SNI domain in UTF-8>

Hex string for t.me/proxy:

ee<32 hex token><hex-encoded SNI>

Validation: HMAC ClientHello with a base secret (one per port). Uniqueness is based on the SNI domain from the extension.

Policy System: Access Rules

Policies are an ordered list of rules for each connection. The first unmet rule rejects the connection.

Rule Types

| Rule | Description |

|------|-------------|

| {in_table, Key, Table} | Key is in Table |

| {not_in_table, Key, Table} | Key is not in Table |

| {max_connections, [Key,...], N} | Connections by keys ≤ N |

Keys from Connection

• tls_domain — SNI from fake-TLS
• port_name — port name
• client_ipv4/client_ipv6 — client IP
• {client_ipv4_subnet, Mask} — subnet

Tables are in-memory hash tables, saved on config reload, lost on restart.

Policy for Personal Proxies

Basic policy:

{policy, [
  {in_table, tls_domain, personal_domains},
  {max_connections, [tls_domain], 30}
]}

• Whitelist: tls_domain in personal_domains.
• Limit: ≤30 simultaneous connections per domain (prevents link sharing).

Additions:

{max_connections, [client_ipv4], 30},
{not_in_table, client_ipv4, ip4_blacklist}

Launching a Standard Personal Proxy

sys.config

{mtproto_proxy, [
  {ports, [
    #{name => mtp_handler,
      listen_ip => "0.0.0.0",
      port => 443,
      secret => <<"d0d6e111bada5511fcce9584deadbeef">>,
      tag => <<"dcbe8f1493fa4cd9ab300891c0b5b326">>}
  ]},
  {allowed_protocols, [mtp_fake_tls]},
  {policy, [
    {in_table, tls_domain, personal_domains},
    {max_connections, [tls_domain], 100}
  ]}
]}

Domain Registration

mtp_proxy eval '
  mtp_policy_table:add(personal_domains, tls_domain, "alice42.example.com").'

Domain activates instantly.

Key Points

• Personal SNI domains enable access control and analytics without changing the base secret.
• Policies are checked in O(1), scaling to thousands of users.
• Erlang ensures connection isolation and zero downtime.
• Policy tables are managed runtime via Erlang RPC.
• A 30-connection limit per domain prevents abuse.

— Editorial Team
