Layered Application Architecture: Sub-Layer Hierarchy and Data Models

Layered architecture structures applications by dividing functionality into isolated layers: a facade layer for external access, a logic layer for business rules, and a persistence layer for data storage. Each layer breaks down into sub-layers—facade, logic, and data access—enabling one-way interactions between layers and two-way data exchange between models.

Core Components of a Single-Tier Application

A single-tier application combines three key functional groups:

• Layered functionality: Isolated layers with one-way interactions between adjacent layers and sub-layers.
• Cross-cutting functionality: Shared mechanisms available to all layers, like logging or security.
• Dataflow functionality: Data transfer operations, including:

- Data mapping to transform between data models.

- Data binding to link data with the UI.

- Data serialization for exchanging with external systems via data transfer channels.

Layer interactions follow a strict hierarchy: adjacent layers exchange data one-way, while data models communicate two-way. The application connects with external consumers (data consumers/producers) through an application input interface and with external data sources (local or remote) via an application output interface.

Local data sources include files, USB/COM/LPT ports. Remote sources cover databases, FTP, LDAP, web services, and message brokers.

Layer and Sub-Layer Structure

Each layer includes functionality and associated data models. Sub-layers consist of:

• Facade sub-layer: External API (public methods).
• Logic sub-layer: Internal layer logic.
• Data access sub-layer: Access to external sources.

Interaction examples:

• Facade layer: UI event handlers or API endpoints.
• Logic layer: Coordinates business logic (application logic).
• Persistence layer: Data access objects (DAOs).

The logic sub-layer of the facade layer generates UI content (e.g., view templates in ASP.NET MVC) and validators (like UniqueValueValidator querying the database via the data access sub-layer).

The logic sub-layer of the logic layer implements domain logic, interacting with persistence for reference data or in recursive algorithms.

External Interfaces and Application Boundaries

• Application upper boundary: Gateway to external consumers via input interface (visual forms, server-side sockets, timers).
• Application lower boundary: Gateway to data sources via output interface (sockets, database drivers).

Data access from facade/logic layers:

• Direct to local sources.
• Via output interface to remote sources.
• Through persistence layer to databases.

The persistence layer focuses on storing and managing persistent data.

Architecture Examples

Structural diagrams illustrate use in web services, report viewers, and ASP.NET MVC.

In a report viewer:

• Facade sub-layer: Visual form with report viewer component.
• Logic sub-layer: Report generator using templates (report templates) and data from the data access sub-layer.
• Data access sub-layer: Queries to persistence layer for report data.

Multi-tier architectures extend single-tier: each tier is a layered application, covering Client-Server, Event-Driven, Pipes and Filters, SOA, and Microservices.

Key Takeaways

• Layering (facade, logic, persistence) ensures isolation and scalability.
• Sub-layers (facade, logic, data access) standardize APIs and logic.
• One-way layer interactions minimize dependency cycles.
• Dataflow (mapping, binding, serialization) streamlines data transfers.
• Clear application boundaries (input/output interfaces) separate internal and external contexts.
