Status-Based RBAC in JMatrixPlatform: Lifecycle-Aware Access Control

JMatrixPlatform implements Role-Based Access Control (RBAC) by binding permissions to object statuses. Every object has a type and a lifecycle — a defined sequence of statuses that reflect its current state. When an object is created, its type and associated lifecycle are specified; the initial status defaults to the first in that lifecycle or is explicitly overridden in the createAction.

A single object type can support multiple lifecycles. For example:

| Object | Type | Lifecycle | Status | Available Next Statuses |

|--------|------|-----------|--------|--------------------------|

| Obj1 | Type1| LC1 | Stat1 | Stat1*, Stat2 |

| Obj2 | Type1| LC2 | Stat4 | Stat1–4* |

| Obj3 | Type1| LC3 | Stat2 | Stat1–3* |

Typical lifecycles include:

• Documentation: Draft → Published → Review → Archived → Issued
• Reference data: New → Active → Deprecated

Status transitions occur via promote (forward) or demote (backward), with full audit logging in the object_states table:

create table object_states (
    object_id uuid not null,
    policy_state varchar(100) not null,
    user_id uuid not null,
    state_start timestamp not null,
    state_end timestamp
);

Audit logs enable process delay analysis: SELECT user_id FROM object_states WHERE policy_state = ? AND (state_end - state_start) >= ?.

Configuring Roles and Policies

Roles extend JRole:

@JModelPart
public final class ARLReferenceAdmin extends JRole {
  public final static ARLReferenceAdmin ROLE = new ARLReferenceAdmin();

  @Override
  public Set<JRole> getParents() {
    return Set.of(ARLRefDesigner.ROLE, ARLRefChangeManagementAdmin.ROLE, ARLRefApprover.ROLE);
  }

  @Override
  public String getDescription() {
    return "Reference Data Administrator";
  }
}

Lifecycles extend JPolicy:

@JModelPart
public final class ALCReference extends JPolicy {
  public final static ALCReference POLICY = new ALCReference();

  @Override
  public Set<JType> getTypes() {
    return Set.of(ATPReference.TYPE);
  }

  @Override
  public List<JState> getStates() {
    return List.of(New.STATE, Active.STATE, Inactive.STATE);
  }

  public static final class New extends JPolicy.JState {
    public static final New STATE = new New();
    @Override
    public Set<RoleAccess> getAccess() {
      return Set.of(new RoleAccess(ARLReferenceAdmin.ROLE, AccessType.ALL));
    }
  }

  public static final class Active extends JPolicy.JState {
    public static final Active STATE = new Active();
    @Override
    public Set<RoleAccess> getAccess() {
      return Set.of(
        new RoleAccess(JPublic.ROLE, AccessType.READ),
        new RoleAccess(ARLReferenceAdmin.ROLE, AccessType.PROMOTE, AccessType.DEMOTE));
    }
  }

  public static final class Inactive extends JPolicy.JState {
    public static final Inactive STATE = new Inactive();
    @Override
    public Set<RoleAccess> getAccess() {
      return Set.of(
        new RoleAccess(JPublic.ROLE, AccessType.READ),
        new RoleAccess(ARLReferenceAdmin.ROLE, AccessType.DEMOTE));
    }
  }
}

AccessType values:

• ALL: Full control
• READ: View only
• CREATE: Create new instances
• MODIFY: Edit existing data
• DELETE: Remove objects
• RELEASE: Version management
• PROMOTE: Advance to next status
• DEMOTE: Revert to previous status
• CHECKIN: Upload files
• CHECKOUT: Download files

Object creation:

JDomainObject obj = new JDomainObject();
obj.create(ctx, ATPDocuments.TYPE, ALCDocument.POLICY);

The platform validates CREATE permission against the initial status. Status transitions use:

obj.promote(ctx); // forward
obj.demote(ctx);  // backward

Database-Level Authorization Mechanisms

JWT roles integrate with Keycloak, and row-level filtering is applied directly in SQL queries — data never leaves the database without authorization.

Maximum Access

JSystemAdmin bypasses all checks for maximum throughput.

Status-Based Access

Example access matrix:

| Role | New | Active | Deprecated |

|-------------------|------------|-----------------------|--------------|

| ARLReferenceAdmin | ALL | READ, PROMOTE, DEMOTE | READ, DEMOTE |

| JPublic | #NOACCESS | READ | READ |

For JPublic: WHERE policy_state IN ('ALCReference.Active', 'ALCReference.Inactive').

For administrators: no status restrictions. Optimization note: ~100 statuses max per policy; temp-table-based filtering under consideration.

Property-Based Filtering

In development. Recursive relationship traversal for access checks is currently inefficient.

Key Takeaways

• Statuses are natively embedded into RBAC — enabling fine-grained, non-destructive access control.
• Full status audit trail in object_states supports process analytics and compliance reporting.
• SQL-level filtering ensures sensitive data never leaves the database without explicit authorization.
• Every promote/demote action is logged with user ID and timestamp.
• Seamless Keycloak role synchronization into JWT tokens.

— Editorial Team
