Rsync hardlink for rollback on ext4 Linux

System Rollback on ext4 Using rsync and Hardlinks: A Practical Implementation

Standard Linux installations on ext4 lack built-in snapshot support, making quick rollbacks to previous states challenging. Backup tools like borg or restic focus on long-term data storage rather than local rollback. Restoring from a full backup takes hours and involves processing large volumes, which is inefficient for fixing local configuration errors or post-update issues.

The solution minimizes dependencies: no need to change the file system, use LVM, or adopt specialized FS like Btrfs/ZFS. The approach relies on rsync with hardlink support for deduplication.

How It Works: rsync + Hardlinks

rsync synchronizes directories by copying only changes. The --link-dest option allows referencing a previous snapshot: unchanged files are reused via hardlinks, minimizing storage usage. A hardlink is an additional name for the same inode, ensuring zero overhead for unchanged data.

Basic command to create a snapshot:

rsync -aHAX --numeric-ids --delete --link-dest="$PREV" "$SRC" "$DEST_TMP/"

• -a: Archive mode (recursive, preserves permissions, timestamps).
• -H: Preserves hardlinks.
• -A: Preserves ACLs.
• -X: Preserves extended attributes.
• --numeric-ids: Uses numeric UID/GID.
• --delete: Removes extra files in the target directory.

This brings the current state to a snapshot, copying only the delta.

Snapshot Storage Structure

Snapshots are stored in .infra_snapshots/ as regular directories with timestamps:

.infra_snapshots/
├── system/
│   ├── 2026-03-01_00-30-00/
│   ├── 2026-03-02_00-30-00/
│   └── LATEST -> 2026-03-02_00-30-00/
├── docker/
│   ├── 2026-03-01_23-30-00/
│   └── LATEST -> 2026-03-01_23-30-00/

The LATEST symlink points to the most recent snapshot for automation. Separating system and docker isolates system files from container data: Docker volumes are excluded to avoid issues with mutable data.

Creation process:

• Create a temporary directory .tmp-YYYY-MM-DD_HH-MM-SS.
• Run rsync into it.
• Rename atomically: mv -T "$TMP_DEST" "$FINAL_DEST".
• Update LATEST: ln -sfn "$FINAL_DEST" "$LATEST_LINK".

This ensures atomicity: the snapshot is either complete or absent.

Restoring State

Rollback involves reverse synchronization with a dry-run for preview:

rsync -aHAX --numeric-ids --delete --dry-run "$SNAP/" "/"

After verification, remove --dry-run to apply. rsync will bring the root system to the snapshot state, deleting new files and restoring old ones via hardlinks.

For Docker: similarly, but only on container directories, excluding volumes.

Limitations of the Approach

• Lack of System Atomicity: rsync reads files sequentially; the system may change during creation. Snapshots are file-consistent but not instantaneous.
• Mutable Data: Logs, databases, and temp files can be in an intermediate state. Exclude them from rsync using --exclude.
• Disk Space: New file versions occupy space; periodically clean up old snapshots.
• Not for High-Load Production: Suitable for servers/desktops with low activity during snapshot creation.

| Scenario | Creation Time (approx.) | Disk Usage |

|----------|---------------------------|---------------|

| Daily system | 2-5 min | 100-500 MB |

| Docker after updates | 1-3 min | 50-200 MB |

Automation

Integrate into cron for daily snapshots:

• 00:30: system.
• 23:30: docker.

The script should log rsync output, check exit codes, and notify on errors.

Key Points:

• rsync with --link-dest emulates snapshots on ext4 without changing the FS.
• Hardlinks provide deduplication: unchanged files are not duplicated.
• Atomicity via tmp-directories prevents partial snapshots.
• Separating system/docker improves rollback accuracy.
• Dry-run is essential before restore for safety.

The approach is transparent, uses only standard Linux utilities, and scales to any ext4 system.

— Editorial Team
