Setting Up VLESS VPN on OpenWRT with Passwall: Step-by-Step Guide

Passwall on OpenWRT lets you deploy a VLESS VPN for your entire LAN. This ensures traffic privacy, bypasses blocks, and enables double VPN chaining. Requirements: an OpenWRT router (minimum 256 MB RAM for full version) and a valid VLESS server subscription.

First, reset your device to factory settings to remove conflicting software—other VPN clients, DoH/DoT, or traffic analyzers.

Router Preparation

• Connect via LAN to your router (IP 192.168.0.1 or 192.168.1.1).
• In the web interface, go to System → Backup/Flash Firmware and click Perform reset.
• After reboot, configure WAN: enter IP, gateway, and DNS from your ISP. If MAC filtering is active, change the WAN interface MAC in Network → Interfaces → Devices → WAN.

Verify internet access on client devices.

Installing Passwall

Connect via SSH:

• Windows: Use PuTTY.
• macOS/Linux: Run ssh [email protected] (replace IP as needed).

Run this one-liner command:

rm -f passwallx.sh && wget https://raw.githubusercontent.com/amirhosseinchoghaei/Passwall/main/passwallx.sh && chmod 777 passwallx.sh && sh passwallx.sh

• Choose option 1 (RAM <256 MB) or 2 (>256 MB).
• Wait for completion, then reboot with reboot.

Optionally restore the hostname:

uci set system.@system[0].hostname='OpenWRT'
uci commit system
echo $(uci get system.@system[0].hostname) > /proc/sys/kernel/hostname
reboot

Check that the Services → Passwall menu appears.

Importing and Activating VLESS Nodes

• Go to Services → Passwall → Node Subscribe → Add, enter a name and the subscription URL from your provider.
• Click Manual Subscription. Nodes will update in the Node List with ping results.
• In Basic Settings → Main, select your node and enable the Main switch. Core status should show RUNNING.

Verify the client’s IP using curl ip.me or whatismyipaddress.com — it should now display the VPN’s IP address.

Logs: Access via Services → Passwall → Watch Logs.

Configuring Device Exclusions

To bypass the VPN on specific devices:

• Disable MAC randomization in the Wi-Fi client settings (on Android, use a stable MAC per network).
• In Services → Passwall → ACL → Add:

- Source: Enter the device’s MAC address.

- TCP/UDP No Redir Ports: Set to All.

- Click Save & Apply.

• Enable the rule and the Main switch.

The excluded device will retain its original ISP-assigned IP.

Use Cases:

• Full LAN privacy protection.
• Selective bypass of regional blocks.
• Double VPN setup: the router hides resources from the first provider, while the client masks its IP from the second.

Key Points to Remember

• Compatibility: Only routers listed at toh.openwrt.org are supported.
• Resources: Use Passwall variant 1 if RAM is under 256 MB to avoid OOM errors.
• Security: Factory reset clears temporary files and conflicts; always use a personal VLESS subscription.
• Verification: Check Node List ping, public IP, and logs.
• Exclusions: A fixed MAC address is mandatory—dynamic MACs break rules.

Troubleshooting Common Issues

| Issue | Solution |

|-------|----------|

| No internet after reset | Reconfigure WAN with ISP details and enable MAC cloning |

| Passwall fails to install | Verify RAM; use variant 1 if memory is limited |

| Nodes not updating | Use manual subscription and check logs for errors |

| VPN won’t connect | Pick a node with low ping and ensure Core status is RUNNING |

| Exclusions not working | Ensure MAC is fixed and ports are set to All |
